Windows NT 4.0 Workstations and Servers
10-16 Part No. 1H9613 June 1997
Selecting a Print Queue for Indirect Printing
Follow the steps in “Creating a Print Queue for Indirect Printing”
to configure a workstation to print from LPT1. This procedure
installs the driver locally on a workstation. Do not share the
printer. When you finish with the “Add Printer” installation
process, do the following:
1. Select the new printer icon.
2. Select “Properties” from the File menu.
3. Select:
• “Ports” tab
• “Add Port”
• “Local Port” from the “Printer Ports screen
4. Click on New Port.
5. Enter a port name that corresponds to an existing server.
For example, Server/ Workstation = NALA and Share name =
DS8650 would result in a \\ NALA \ DS8650 server/queue
that will be available for users.
6. Click on OK.
7. Check the new printer’s properties for consistency with the
media currently in the printer to avoid errors.
