A-4
HDW-2000/M2000/M2000P/S2000/S2000P/M2100/M2100P, DVW-2000/2000P/M2000/M2000P
MSW-2000/A2000/A2000P/M2000/M2000P/M2000E/M2000EP/M2100/M2100P/M2100E/M2100EP
(Continued)
Board Switch No. : Name Factory setting Setting
DIF-109 S700 1 : CPU I/F SEL0 OFF
2 : CPU I/F SEL1 OFF
3 : Factory use OFF _
4 : EVR_SEL ON
5 : RX_RESET OFF
6 : TX_RESET OFF
7, 8 : Not use OFF _
DM-123 S101 * : Y-RF LPF & EQ TEST NORMAL POSITION _
S301 * : C-RF LPF & EQ TEST NORMAL POSITION _
S1701 1 : Y MUTING OFF
2, 3 : Factory use OFF _
4 : C MUTING OFF
5 : COMB OFF
6 - 8 : Factory use OFF _
S1801 1 : Factory use OFF _
2 : IMP OFF OFF
3, 4 : Factory use OFF _
5 : AGC OFF OFF
6 : DO ADJ OFF
7, 8 : Not use OFF _
DPR-155 S800 1 : Factory use OFF (ON * ) _
2 - 4 : Factory use OFF _
DSP-109 S11 1 : Factory use OFF _
2 : Factory use ON _
EQ-84 S200 1, 2 : Factory use OFF _
S201 1, 2 : Factory use OFF _
S1100 : MAINTE OFF
HIF-1 S50 1 - 4 : Factory use OFF _
S900 1 - 4 : Factory use OFF _
HPR-1 S200 1 - 4 : Factory use OFF _
S201 1 - 4 : Factory use OFF _
S202 1 - 4 : Factory use OFF _
S203 1 - 4 : Factory use OFF _
S600 1 - 4 : Factory use OFF _
S601 1 - 4 : Factory use OFF _
S602 1 - 4 : Factory use OFF _
S603 1 - 4 : Factory use OFF _
S900 1 - 4 : Factory use OFF _
*: Board No. suffix -11 and -12 only
Setting Check Sheet
