1-15-2. VTR Constant Values Settings of Editor
Set the VTR constant values according to the table 1-15-2 below when the editor which needs the setting
of VTR constant values is connected. Moreover, the change of VTR constant values are required when
the operation mode (HDW series : 50/59.94 Hz mode, DVW/MSW series : 525/625 mode) is switched by
setup menu of this unit.
n
When remote-controlling this unit by the editor, set the setup menu ITEM-401: FUNCTION MODE
AFTER CUE-UP to “STOP”.
Table 1-15-2. VTR Constant Values Settings of Editor
(Standard value is expressed in hexadecimal.)
*: Set the data of No.8 of the VTR CONSTANT 1 to “0A” for the following editors.
. BVE-900 ROM versions earlier than 1.08
. BVE-600 ROM versions earlier than 1.01
1-15. Settings and Adjustment when External Equipment is Connected
Model Operation
Mode
MSW-A2000,
MSW-A2000P 525/60
VTR CONSTANT 1
1 2 3 4 5 6 7 8
B0 61 00 96 07 07 05 8A
Data No.
*
VTR CONSTANT 2
1 2 3 4 5 6 7 8
0A 07 FB 00 81 4B FF 5A
625/50 B1 61 00 7D 07 07 05 8A * 0A 07 FB 00 83 3B FF 4B
MSW-2000 525/60 B0 62 00 96 07 07 05 8A * 0A 07 FB 00 81 4B FF 5A
625/50 B1 62 00 7D 07 07 05 8A * 0A 07 FB 00 83 3B FF 4B
HDW-2000,
HDW-M2000,
HDW-M2000P,
HDW-S2000,
HDW-S2000P
59.94, 29.97P 20 E2 00 96 07 07 03 8A * 0D 08 00 00 81 3D FF 5A
50, 25P 21 E2 00 7D 07 07 03 8A *
*
0D 07 00 00 83 3B FF 4B
24P, 23.98P 22 E3 00 78 07 07 03 8A 0D 07 00 00 83 3B FF 4B
* 24P, 23.98P 22 E3 00 78 07 07 03 8A 0D 07 00 00 83 3B FF 4B
HDW-M2100,
HDW-M2100P 59.94, 29.97P 20 E3 00 96 07 07 03 8A * 0D 08 00 00 81 3D FF 5A
50, 25P 21 E3 00 7D 07 07 03 8A * 0D 07 00 00 83 3B FF 4B
MSW-M2000,
MSW-M2000P,
MSW-M2000E,
MSW-M2000EP
525/60 B0 60 00 96 07 07 05 8A * 0A 07 FB 00 81 4B FF 5A
625/50 B1 60 00 7D 07 07 05 8A * 0A 07 FB 00 83 3B FF 4B
MSW-M2100,
MSW-M2100P,
MSW-M2100E,
MSW-M2100EP
525/60 B0 63 00 96 07 07 05 8A * 0A 07 FB 00 81 4B FF 5A
625/50 B1 63 00 7D 07 07 05 8A * 0A 07 FB 00 83 3B FF 4B
DVW-2000,
DVW-2000P 525/60 B0 14 00 96 07 07 05 8A * 0A 07 FB 00 81 4B FF 5A
625/50 B1 14 00 7D 07 07 05 8A * 0A 07 FB 00 83 3B FF 4B
DVW-M2000,
DVW-M2000P 525/60 B0 04 00 96 07 07 05 8A * 0A 07 FB 00 81 4B FF 5A
625/50 B1 04 00 7D 07 07 05 8A * 0A 07 FB 00 83 3B FF 4B
Data No.
