12 • Getting Started ER-390M
Keyboards
The ER-390M keyboard includes 90 key positions with the default legends and key
assignments as shown below. The keyboard legend sheet can be replaced by lifting the
protective plastic cover.
Programmable key locations are shown with a bold border.
