6-31
LS 3070 Product Reference Guide: Programming
Terminal Specific RS-232C Defaults
Two RS-232C hosts are set up with their own parameter default settings.
Selecting the ICL or Nixdorf RS-232C terminal will set the defaults listed
below. These defaults take precedence over standard defaults. So, if you’ve
selected Nixdorf RS-232C, then select the standard defaults, the Nixdorf
defaults will still take precedence.
Table 6-4. Terminal-Specific RS-232 Defaults
Parameter Standard ICL NIXDORF
Fixed Host Select No Host RS-232C RS-232C
Transmit Code ID No Yes Yes
Data Transmission Format Data as is Data/Suffix Data/Suffix
Suffix CR/LF (7013) CR (1013) CR (1013)
Baud Rate 9600 9600 9600
Parity Even Even Odd
Check Parity Enabled Enabled Enabled
Hardware Handshaking None None None
Software Handshaking None None None
Serial Response Time-out 2 Sec. 2 Sec. 2 Sec.
Stop Bit Select Two One One
ASCII Format 7-Bit 8-Bit 8-Bit
Beep On Disabled Disabled Disabled
RTS Line State Low High Low
RS-232C UPC-A Code ID “A” “A” “A”
RS-232C UPC-E Code ID “A” “E0” “C0”
RS-232C EAN-8 Code ID “A” “FF” “B”
RS-232C EAN-13 Code ID “A” “F” “A”
RS-232C Code 39 Code ID “B” “C” “M”
RS-232C Codabar Code ID “C” “N” “N”
