English _
!
setuP
Use the up/down ($%) button to move to a desired item.
CHANNEL: Select a channel to set the alarm.
You can set the alarm for only one channel.
TYPE: Set the sensor input system.
: The sensor does not work.
: The sensor is always open.
The alarm will sound when the sensor is closed.
: The sensor is always closed.
The alarm will sound when the sensor is open.
DURATION: Specify the duration for which the DVR makes the alarm recording when an alarm sounds.
When done, select .
Your setting will be applied.
If you select , the selected channel will be reset to the default, and if selecting
, all the channels will be reset to the factory default.
To return to the previous menu, select .
interval setup
You can specify the interval for Auto Sequence, or PIP (Picture In Picture) mode.
See the previous section to repeat steps 1~3. (Page 30)
Use the up/down ($%) button to select setuP>, and press [OK].
Use the up/down ($%) button to move to a desired item.
Use the up/down ($%) button to move to a desired item.
SEQUENCE SCREEN: In Live full screen, specify the
auto sequence interval for each camera channel.
PIP SCREEN: Specify the interval for auto sequence for
the sub picture in PIP mode.
EVENT UPDATE: Specify the interval of updating the
event list for incoming events.
If the interval is set to 10 seconds, the next event can be
updated 10 seconds after the fi rst event was registered
to the event list.
When done, select .
Your setting will be applied.
If you select , the settings will be restored to the factory default.
To return to the previous menu, select .
.
~
`
~
-
-
-
~
.
.
.
.
.
~
~
~
.
.
ALARM SETUP
DEFAULT ALL-DEFAULT ESC
CHANNEL CH1
TYPE NORMAL OPEN
DURATION 05 SEC
OK
CONFIGURATION
ESC
HDD MANAGEMENT
CAMERA SETUP
MOTION SETUP
ALARM SETUP
INTERVAL SETUP
DATE/TIME SETUP
PASSWORD SETUP
BUZZER SETUP
INTERVAL SETUP
DEFAULT ESC
SEQUENCE SCREEN 01 SEC
PIP SCREEN 01 SEC
EVENT UPDATE 600 SEC
OK
