_ setup
setup
Use the up/down ($%) button to set the “tOP OsD
OFFset”.
The icon bar in the upper corner of the Live screen will be
removed up or down.
When done, select .
Your setting will be applied.
If you select , the settings will be restored to
the factory default.
To return to the previous menu, select .
recOrD
You can confi gure the record and recording schedule settings.
record setup
You can set options of the record quality, frame rate and pre alarm record.
Press the [meNu] button on the remote control or the
front panel.
The “Dvr lOG-iN” dialog appears.
Enter the password and select .
The “maiN meNu” screen appears.
Use the up/down ($%) button to select , and
press [OK].
The “recOrD” setting screen appears.
Use the up/down ($%) button to select setuP>, and press [OK].
The “recOrD setuP” screen appears.
Use the up/down ($%) button to move to a desired item.
QUALITY: Select the quality from Highest, High and
Normal.
The remaining time will change according to the quality.
FRAME RATE: Set the frame rate per second.
The higher the frame rate is, the more natural the video
becomes but the remaining recordable time will be
shortened.
.
.
.
1.
.
.
.
.
~
~
OSD SETUP
TOP OSD OFFSET 0
OK
DEFAULT ESC
MAIN MENU
EXIT
DISPLAY SETUP
RECORD
CONFIGURATION
EXTERNAL DEVICE
BACK-UP
FIRMWARE UPGRADE
FACTORY DEFAULT
LANGUAGE ENGLISH
SHUTDOWN
RECORD
ESC
RECORD SETUP
SCHEDULE SETUP
RECORD SETUP
DEFAULT ESC
QUALITY HIGH
FRAME RATE 30 FPS
PRE ALARM RECORD OFF
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
HDD REMAINING 236GB/320GB
TIME REMAINING D-14 H-11 M-25
OK
