Introduction Section 2-3

SPECIFICATIONS

Specifications may vary depending on tractor model, tire size and bucket used and are subject to change without notification. Tractor

must be equipped with ROPS and seat belt that will provide greater safety and installation of backhoe subframe.

95HD

GENERAL DATA

A

Digging Depth (two foot flat bottom) . . . . . . . . . . . . . . 114"

B

Reach from center line of Swing Pivot . . . . . . . . . . . . . 153"

C

Loading Height (bucket at 60°). . . . . . . . . . . . . . . . . 96"

D

Load Reach . . . . . . . . . . . . . . . . . . . . . . . . . . 43"

E

Maximum Leveling Angle . . . . . . . . . . . . . . . . . . . 11.5°

F

Swing Arc . . . . . . . . . . . . . . . . . . . . . . . . . . . 180°

G

Transport Height (maximum). . . . . . . . . . . . . . . . . . 100"

H

Transport Overhang . . . . . . . . . . . . . . . . . . . . . . 55"

I

Bucket Rotation . . . . . . . . . . . . . . . . . . . . . . . . 185°

J

Stabilizer Spread, down position . . . . . . . . . . . . . . . . 117"

K

Stabilizer Spread, up position . . . . . . . . . . . . . . . . . 67"
Shipping Weight (less bucket) . . . . . . . . . . . . . . . . . 1818 lbs.
Bucket Digging Force . . . . . . . . . . . . . . . . . . . . . 5872 lbs.
Dipperstick Digging Force . . . . . . . . . . . . . . . . . . . 3800 lbs.
Operating Pressure . . . . . . . . . . . . . . . . . . . . . . 2500 PSI

NOTE: See Illustrations of Specifications on Page 2-4

BUCKET DATA

BUCKET WIDTH

SAE STRUCK CAPACITY

SAE HEAPED CAPACITY

SHIPPING WEIGHT

12" H.D.

1.80 cu. ft.

1.95 cu. ft.

159 lbs.

18" H.D.

2.70 cu. ft.

3.03 cu. ft.

192 lbs.

24" H.D.

3.60 cu. ft.

4.12 cu. ft.

226 lbs.

36" Grave

4.40 cu. ft.

5.03 cu. ft.

279 lbs.

CYLINDER DATA

CYLINDER

PISTON DIA. STROKE

RETRACTED LENGTH

EXTENDED LENGTH

ROD DIA.

Boom

3.25"

23.88"

34.00"

57.88"

1.75"

Dipperstick

3.25"

25.56"

35.25"

60.81"

1.75"

Bucket

3.00"

22.00"

32.00"

54.00"

2.00"

Swing

3.00"

10.78"

7.16"

17.94"

1.50"

Stabilizer

3.00"

17.69"

26.25"

43.94"

1.50"

INTRODUCTION

INTRODUCTION
