-66-
For Machines Mfg. Since 8/09 Model SB1027 P A R T S
Gearbox Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 PSB10240301 GEARBOX PLATE 325 PSB10240325 BELT PULLEY GEAR
302 PK70M KEY 8 X 8 X 12 326 PCAP24M CAP SCREW M5-.8 X 16
303A PSB10240303A SPINDLE GEAR HUB ASSEMBLY 327 PSB10240327 BULL GEAR PINION BEARING CAP
303 PSB10240303A SPINDLE GEAR HUB 328 PSB10240328 WAVE SPRING WASHER
304 PSB10240304 SPINDLE BULL GEAR 329 P6203VV-N DEEP GROOVE BALL BEARING 6203VV NSK
305 PSB10240305 BEARING SLEEVE 330 PSB10240330 PINION GEAR 30T
306 P6908VV-N DEEP GROOVE BALL BEARING 6908VV NSK 331 PSS20M SET SCREW M8-1.25 X 8
307A PSB10240307A BEARING SPACER ASSEMBLY 332 PSB10240332 PINION GEAR SHAFT
307 PSB10240307A BULL GEAR BEARING SPACER 333 PK19M KEY 5 X 5 X 14
308 PSB10240307A BULL GEAR BEARING SPACER 334 PK14M KEY 5 X 5 X 18
309 PR38M INT RETAINING RING 62MM 335 PZERK005 GREASE FITTING ST 1/8 PT
310 PSB10240310 SPACER 336 PSB10240336 GEARBOX HOUSING
311 PSB10240303A SPANNER LOCK WASHER 337 PCAP14M CAP SCREW M8-1.25 X 20
312 PSB10240303A SPANNER NUT 339 PSB10240339 BULL GEAR SHIFT PINION
313 PSB10240313 BEARING SLEEVE WASHER 340 PSB10240340 HI-LOW DETENT PLATE
314 PSB10240314 STEP PIN 341 PCAP33M CAP SCREW M5-.8 X 12
315 PSB10240315 COMPRESSION SPRING 342 PRP02M ROLL PIN 3 X 16
316 PFH71M FLAT HD CAP SCR M5-.8 X 8 343 PSS26M SET SCREW M5-.8 X 6
317 PSB10240317 BLOCK 344 PSB10240344 HI-LOW PINION BLOCK
318 PSB10240090 OILCUP 1/8 345 PCAP16M CAP SCREW M4-.7 X 16
321 PSB10240321 DOUBLE-END STUD 346 PSB10240346 HI-LOW DETENT PLUNGER
322 PLW05 LOCK WASHER 7/16 347 PSB10240005 COMPRESSION SPRING
323 PN19 HEX NUT 7/16-14 348 PSB10240348 HI-LOW LEVER
324 PN09 HEX NUT 5/8-11 349 PSB10240018 ROUND KNOB 1/4-20
