PPP (Dial-up) Settings
2 Set “CONNECT” to “N”.
3 Click the [CAMERA SET] and [RECORD
MODE SET] buttons and make the
respective settings.
4
Click the [LOCAL SERVER SET] button.
The LOCAL SERVER SET screen will be
displayed.
•
LOCAL SERVER USE: Set to “USE”.
•
LOCAL SERVER IP ADDRESS:
The computer that has the Network
Archiving Software installed becomes a
local server that can be accessed via the
Internet. Type in the global IP address
that has been assigned by the ISP in this
case.
•
FTP PORT NUMBER: Type in “21”.
•
FTP PASSIVE: Set to “NO USE”.
•
CAMERA-ID: Type in a unique
4-character camera name.
5 Click the [SET TO CAMERA] button.
The settings will be loaded into the camera.
6 Click the [SAVE INFO FILE] button.
The settings will be applied to the Network
Archiving Software.
7
Close the Camset window.
Note:
•
The camera cannot be accessed using the
computer’s web browser while the camera is
connected to the modem. Use a wired LAN
or wireless LAN to access the camera.
•
Only alarm image data and alarm data can
be transmitted by means of PPP connections.
5 6
3
2 4
