M1109 Combo Lathe/Mill
PA
RT
S
4000 Series Parts List
REF
PART�#
DESCRIPTION
REF
PART�#
DESCRIPTION
4001
XPK81M
KEY�6�X�6�X�12
4041
XM11094041 COMPRESSION�SPRING
4002
XM11094002 GEAR�SHAFT
4042
XM11094042 STEEL�BALL�6.5MM
4003
XM11094003 LOCK�COLLAR
4043
XM11094043 SPECIAL�SET�SCREW�M6-1.0�X�8
4004
XM11094004 SET�SCREW�M6-1.0�X�12
4044
XM11094044 COMPRESSION�SPRING
4005
XM11094005 SPECIAL�SET�SCREW�M6-1.0�X�12
4045
XM11094045 STEEL�BALL�5MM
4006
XM11094006 WORM�GEAR
4046
XM11094046 SHIFTING�FORK
4007
XM11094007 GEAR�(40-TOOTH)
4047
XPK02M
KEY�5�X�5�X�40
4008
XM11094008 SPECIAL�SET�SCREW�M5-.8�X�8
4048
XM11094048 SHIFTING�FORK�SHAFT
4009
XM11094009 SPACER
4049
XM11094049 SLEEVE
4010
XM11094010 GEAR�(60-TOOTH)
4050
XM11094050 GIB
4011
XPR09M
EXT�RETAINING�RING�20MM
4051
XM11094051 HALF�NUT�SET
4012
XM11094012 CLUSTER�GEAR
4052
XM11094052 ALIGNMENT�PINS�6�X�8MM
4013
XM11094013 SHAFT
4053
XPSB06M
CAP�SCREW�M6-1�X�25
4014
XM11094014 CASE
4054
XPLW03M
LOCK�WASHER�6MM
4015
XM11094015 SPECIAL�SET�SCREW�M5-.8�X�16
4055
XM11094055 SPECIAL�SET�SCREW�M4-.7�X�8
4016
XM11094016 SPECIAL�SET�SCREW�M6-1.0�X�20
4056
XM11094056 SLEEVE
4017
XPSB79M
CAP�SCREW�M5-.8�X�35
4057
XM11094057 MIDDLE�GEAR
4018
XM11094018 APRON�END�BLOCK
4058
XM11094058 STUB�HUB
4019
XPR03M
EXT�RETAINING�RING�12MM
4059
XM11094059 BEARING�SLEEVE
4020
XPK29M
KEY�4�X�4�X�8
4060
XPK125M
KEY�4�X�4�X�28
4021
XM11094021 GEAR�(30-TOOTH)
4061
XM11094061 FLAT�SPRING
4022
XM11094022 SPACER
4062
XM11094062 HAND�WHEEL
4023
XM11094023 SHAFT
4063
XPN42M
ACORN�NUT�M12�X�1.5
4024
XM11094024 ANGLE�BLOCK
4064
XM11094064 SLEEVE
4025
XM11094025 TAPER�PIN
4065
XM11094065 DIAL
4026
XM11094026 LEVER
4066
XPS02M
PHLP�HD�SCR�M4-.7�X�12
4027
XM11094027 FEMALE�KNOB�M8-1.25�X�40MM
4067
XM11094067 FLANGE�SLEEVE
4028
XPSS34M
SET�SCREW�M5-.8�X�16
4068
XM11094068 GEAR�SHAFT
4029
XM11094029 SPECIAL�SET�SCREW�M5-.8�X�8
4069
XM11094069 WORM�SHAFT
4030
XM11094030 COVER
4070
XM11094070 SADDLE�KEY�4�X�28
4031
XPS05M
PHLP�HD�SCR�M5-.8�X�8
4071
XP8106
THRUST�BEARING�8106
4032
XPN06M
HEX�NUT�M5-.8
4072
XPSB24M
CAP�SCREW�M5-.8�X�16
4033
XM11094033 SPECIAL�SET�SCREW�M5-.8�X�25
4073
XM11094073 FIXED�FLANGE�HUB
4034
XM11094034 STUB�HUB
4074
XP8106
THRUST�BEARING�8106
4035
XM11094035 TAPER�PIN
4075
XM11094075 TANG�WASHER
4036
XM11094036 FLANGE�HUB
4076
XM11094076 SPANNER�NUT�M30-1.5
4037
XPFH25M
FLAT�HD�SCR�M4-.7�X�12
4077
XM11094077 PLATE
4038
XM11094038 FEMALE�KNOB�M8-1.25�X�40MM
4078
XPS05M
PHLP�HD�SCR�M5-.8�X�8
4039
XM11094039 LEVER
4079
XM11094079 HOUSING
4040
XM11094040 LEVER�HUB
