Other DIP switch settings
This printer has 10 DIP switches located on the back, as mentioned earlier in this manual.
The following information is provided to help you should you ever need to adjust the
printer's performance in the future. We recommend that switches other than 7 through 9
for print intensity ordinarily be left alone.
Print Type Items that can be changed with the DIP switches
Normal printing (Note 1) • Overall print intensity (7 levels from +3 to —3)
(printing from Windows) • Sets slow speed mode (Note 2)
Test print • Change of film rolls (5 types)
• Change of print media/size (3 types/2 types)
• Overall print intensity (7 levels from +3 to —3)
Note 1: Windows settings take priority over DIP switch settings.
Note 2: This sets Low print speed which is useful for areas with high intensity
or patterns.
Paper Types
Plain Paper
Coated Paper,
Presentation
grade paper
OHP Film,
Iron-on Transfer
Sheets
Film Roll Types
Paper Sizes Print Intensity
TL1-11C4H
4 Color, A4
TL1-14C4H
4 Color, A4/SA4
TL1-14C3H
4 Color, A4/SA4
TL1-CBH
Monochrome
A4/SA4
TL1-11C3H
3 Color, A4
A4
S4A
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
+3
(Darkest)
+2
+1
0
(Standard)
-1
-2
-3
(Lightest)
Do not change
this switch setting.
It should always
be set to the 1
(ON) position.
ON 1 2 3 4 5 7 9 6 8 10
0
1
Slow Speed
Mode
(Coated Paper)
