12

Installing the Interactive Whiteboard

99-00667-00 B0

12. Loosen the T-handles on the hanger brackets. Push these brackets towards the flat surface

and then tighten the T-handles.

13. With the assistance of another person, mount the flat-panel display onto a wall mount or onto

a stand.

14. If your flat-panel display has removable handles, remove them to make the overlay’s

installation easier.

15. If there is anything protruding from the front of the flat-panel display that could potentially

scratch the overlay when it’s mounted (for example, a manufacturer’s name or logo) consider
covering it with one of the provided spacing pads.

CAUTION

Don’t lift the flat-panel display by the mounting bracket.

T-handles

Hanger Bracket

Wall Mount

NOTE: Your wall mount

Flat-Panel Display

may appear different from

the one illustrated.
