CONTENTS
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ACCESSORY (SRT-4040 only) . . . . . . . . . . . . . . . . . . . 3
LOCATIONS OF CONTROLS AND INDICATORS . . . . 4
CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ON-SCREEN MENU. . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SETTING THE LANGUAGE AND CLOCK . . . . . . . . . . 12
SUPERIMPOSE DISPLAY . . . . . . . . . . . . . . . . . . . . . . 14
VIDEO CASSETTE TAPES . . . . . . . . . . . . . . . . . . . . . 15
TAPE MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . 17
NORMAL RECORDING . . . . . . . . . . . . . . . . . . . . . . . . 20
AUTOREPEAT RECORDING . . . . . . . . . . . . . . . . . . . 24
ALARM RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . 25
PROGRAM TIMER RECORDING . . . . . . . . . . . . . . . . 28
RECORDING USING AN EXTERNAL TIMER INPUT . 32
SERIES RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . 33
SINGLE IMAGE RECORDING . . . . . . . . . . . . . . . . . . . 34
NORMAL PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . 35
SPECIAL PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . 36
DAY/TIME SEARCH. . . . . . . . . . . . . . . . . . . . . . . . . . . 37
SECURITY LOCK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
CLOCK ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . 38
SELECTING INPUT AND OUTPUT TERMINALS . . . . 38
SETTING THE CASSETTE EJECT MODE . . . . . . . . . 39
SYNCHRONIZATION CONTROL . . . . . . . . . . . . . . . . 40
SETTING FOR RS-485 USE . . . . . . . . . . . . . . . . . . . . 42
CHECKING POWER FAILURE, FAILURE DUE TO
CONDENSATION AND USAGE DURATION . . . . 43
OUTPUT TERMINALS . . . . . . . . . . . . . . . . . . . . . . . . . 44
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
TROUBLESHOOTING GUIDE . . . . . . . . . . . . . . . . . . . 50
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
FEATURES
œ
Tape management function
œ
Clog detection
œ
High-speed Fast Forward/Rewind
œ
Field recording/playback
œ
Audio recording is available in 6-, 18- and 30-hour
modes (T-120)
œ
Audio recording is available in 8-, 24- and 40-hour
modes (T-160)
œ
Autorepeat recording
œ
Series recording function
œ
Alarm recording function
œ
Single image recording function
œ
On-screen mode setting
œ
Integrated time date generator
œ
Day/Time search function
œ
Alarm scan/search function
œ
Forward/Reverse field advance function
œ
30-day memory backup
œ
Security lock
œ
Recording check function
œ
Automatic head cleaning function
œ
Thread check function
œ
Synchronization control function
œ
6, 18 and 30-hour mode recording (T-120)
œ
8, 24 and 40-hour mode recording (T-160)
SRT-4040 only
œ
AC power operation
SRT-4040DC only
œ
DC power operation
When using the RS-485 interface board (VZU-40485),
the VCR can be controlled from a system controller.
ACCESSORY
(SRT-4040 only)
1
Power cord
