2-13

SRX-T420

6. Click the “INSTALLATION” tab.

The INSTALLATION window is displayed.

7. Set the lamp power to 100% in the “LAMP POWER” menu to project an image in 100% black.

(No signal condition)

8. Display the LAMP INFORMATION window in the SERVICE window.

9. Click

the

[START] button in a “Lamp Adjust” menu.

The unit enters the lamp adjustment mode.

10. Wait for fi ve minutes.
11. When the unit enters the lamp adjustment mode, the

value of the internal luminance sensor is displayed on
the status message display.

Adjust “Z Axis Adjust” using the [+]/[_] button so
that the luminance value becomes maximum.

“LAMP POWER” menu

Fig. 2-3c

[+], [_] buttons

[START] button

Fig. 2-3d

Status message
display

Fig. 2-3e
