5. SYSTEM PARAMETERS English
Parameter Function Range
[Default]
Description / Notes
© Siemens plc 1997 G85139-H1750-U049-B
31 26/09/97
P121 Enable/disable RUN button 0 - 1
[1]
0 = RUN button disabled.
1 = RUN button enabled (only possible if P007 = 1).
P122 Enable/disable
FORWARD/REVERSE button 0 - 1
[1]
0 = FORWARD/REVERSE button disabled.
1 = FORWARD/REVERSE button enabled (only possible if P007 = 1).
P123 Enable/disable JOG button 0 - 1
[1]
0 = JOG button disabled.
1 = JOG button enabled (only possible if P007 = 1).
P124 Enable/disable
∆
and
∇
buttons 0 - 1
[1]
0 =
∆
and
∇
buttons disabled.
1 =
∆
and
∇
buttons enabled (only possible if P007 = 1).
Note: This applies for frequency adjustment only. The buttons can
still be used to change parameter values.
P125 Reverse direction inhibit 0 - 1
[1]
0 = Reverse direction disabled. Inhibits reverse commands from ALL
sources (reverse RUN commands result in forward rotation)
1 = Normal operation (FORWARD/REVERSE operation allowed)
P131 Frequency setpoint (Hz) 0.00-400.00
[-]
P132 Motor current (A) 0.0 - 99.9
[-]
P134 DC link voltage (V) 0 - 1000
[-]
P135 Motor RPM 0 - 9999
[-]
P137 Output voltage (V) 0 - 1000
[-]
P140 Most recent fault code 0 - 9999
[-]
The last recorded fault code (see section 6) is stored in this parameter.
This is a copy of the code stored in P930.
P141 Most recent fault code -1 0 - 9999
[-]
This parameter stores the last recorded fault code prior to that stored
in P140/P930.
P142 Most recent fault code -2 0 - 9999
[-]
This parameter stores the last recorded fault code prior to that stored
in P141.
P143 Most recent fault code -3 0 - 9999
[-]
This parameter stores the last recorded fault code prior to that stored
in P142.
P201 Closed loop mode 0 - 2
[0]
0 = Normal operation (closed loop control disabled).
1 = Not used.
2 = Closed loop control using analogue input for transducer feedback
input.
P202
•
P gain (%) 0.0 - 999.9
[1.0]
Proportional gain.
P203
•
I gain (%) 0.00 - 99.99
[0.00]
Integral gain.
0.01% corresponds to the longest integral action time.
P205
•
Sample interval (x 25 ms) 1 - 2400
[1]
Sampling interval of feedback sensor.
P206
•
Transducer filtering 0 - 255
[0]
0 = Filter off.
1 - 255 = Low pass filtering applied to sensor.
P207
•
Integral capture range (%) 0 - 100
[100]
Percentage error above which integral term is reset to zero.
P208 Transducer type 0 - 1
[0]
0 = An increase in motor speed causes an increase in sensor
voltage/current output.
1 = An increase in motor speed causes a decrease in sensor
voltage/current output.
Read-only parameters. These are copies of the values stored in
P001 but can be accessed directly via the serial link.
