APPENDIX G2: 5100-26-IT GAS SENSOR MODULE
Calibration of 5100-26-IT (Supplement to Instructions in Section 6)
1. The calibration of the Model # 5100-26-IT HF gas sensor module is accomplished by using a 5 ppm
Chlorine standard ( Type C kit with # 1260-06 cylinder ). Scale range is 0-10 ppm with 5 ppm being mid-
scale. 5 ppm Cl2 is equivalent to 5 ppm HF.
2. Reference Table 6.1 for the calibration procedure sub menu. This procedure requires the use of the
magnetic wand to activate the keys and confirm each entry step. Follow prompts on the module display as
navigation is detailed in Table 6.1
3. Enter actual span gas concentration that is printed on the cylinder being used when prompted.
4. Refer to the sensor rebuild and electrolyte replacement procedure as detailed in Appendix G1.
