Model 5100-XX-IT Toxic Gas Sensor Module
Page: 31
Operating Range:
Enclosure:
Material - Aluminum:
Polyester powder-coated, sand-cast, copper-free aluminum
Material - Stainless Steel:
316 Stainless Steel
Dimensions: (HxWxD) (differs for 5100-25-IT & 5100-26-IT)
(A1 & A2)
7.9 x 5.7 x 3.9 in. (20.1 x 14.5 x 9.9 cm)
(S1 & S2)
7.6 x 4.4 x 4.9 in. (19.3 x 11.2 x 12.4 cm)
Weight:
(A1 & A2)
3.4 lb. (1.5 Kg)
(S1 & S2)
7.2 lb. (3.3 Kg)
Housing:
NEMA 4X, NEMA 7
Hazardous Area Approval:
Explosion proof, Class 1, Div. I, Groups B, C, D
Group IIB + H2 IP66, IP65, NEMA 4X
Electrical Approvals:
Factory Mutual (FM):
Class 1, Div. I, Groups B, C, D
FM Standards 3600, 3615, 3810
UL:
UL Standard 508A
ATEX (5100-XX-IT):
II 2 G Ex d IIB+H2 T6 Gb Ta = -20
o
C to +50
o
C
Performance Approvals:
FM Performance Approval:
FM Performance Approval (5100-05-IT) (Appendix I)
SIL-2 Certified (5100-04-IT, 5100-05-IT, 5100-06-IT)
CE Mark (5100-05-IT)
ABS
(5100-05-IT)
CQST
Remote Sensor Option (Appendix D):
Distance between sensor and transmitter:
Warranty:
Limited Warranty:
2 years
Specifications subject to change without notice
Ambient Temp (
o
F)
Ambient Temp (
o
C)
Relative Humidity
5100-03-IT O
2
5 to 122
o
F
-15 to 50
o
C
15 – 90%
5100-04-IT CO
- 4 to 122
o
F
-20 to 50
o
C
15 – 90%
5100-05-IT H
2
S (5)
- 40 to 122
o
F
-40 to 50
o
C
15 – 90%
5100-06-IT Cl
2
- 4 to 122
o
F
-20 to 50
o
C
15 – 90%
5100-08-IT ClO
2
- 4 to 122
o
F
-20 to 50
o
C
15 – 90%
5100-10-IT SO
2
- 4 to 122
o
F
-20 to 50
o
C
15 – 90%
5100-12-IT NO
2
- 4 to 122
o
F
-20 to 50
o
C
15 – 90%
5100-21-IT HCl
- 4 to 122
o
F
-20 to 50
o
C
15 – 90%
5100-25-IT NH
3
(4)
+14 to 113
o
F
-10 to 45
o
C
20 – 95%
5100-26-IT HF (4)
+14 to 113
o
F
-10 to 45
o
C
20 – 95%
5100-88-IT CO
2
- 4 to 140
o
F
-20 to 60
o
C
15 – 90%
5100-03-IT 10
feet
5100-06-IT 10
feet
5100-04-IT 15
feet
5100-08-IT 10
feet
5100-05-IT 15
feet
5100-10-IT 15
feet
