Digital Video Recorder User Manual
4
Digital Video Recorder
RECORD
PLAY
REW
FORWARD
STOP
INFO
POWER
SEARCH
CH 1
CH 2
CH 3 CH 4 QUAD/ENTER
1 2 3 4 5 6 7 8 9 10
1 Power button 2 Record button
3 Play button 4 Fast Backward button
5 Fast Forward button 6 Stop button
7 Information button 8 Left /Up /Right /Down buttons
9 Quad/Enter button 10 Search button
Fig2.1 Front Panel
2.3 Back Panel & Interface Terminals
The interfaces on the Back Panel please refer to the entity. There might be slightly difference from below figure. You could
contrast below figure and the entity for realizing the function of every interface.
The Back Panel and interface terminal is shown as Fig2.2 Back Panel.
