102
Operations (Step 5 Operating Using a Web Browser)
Ⅵ
Alarm In
For specifying the camera operation upon
input of alarm signals.
1
IN1/IN2
On : Detect Mode
(Set value: Make, Break, Toggle)
: Alarm Out
(Set value: Not Available, OUT1, OUT2)
: Go to a Preset Position
(Set value: Not Available, Home,
Position 1 to Position 99)
: Return Mode
(Set value: Not Available, Return, Event)
: Return Interval
(Set value: 1 to 65535 seconds)
: Black & White
(Set value: Not Available, Color, Black
& White, Auto)
: Message Packet
(Set value: Available, Not Available)
: FTP
(Set value: Available, Not Available)
: Shutdown
(Set value: Available, Not Available)
Off : Do not use Alarm 1 and Alarm 2.
2
Relay Alarm
On : Alarm Out
(Set value: Not Available, OUT1, OUT2)
: Go to a Preset Position
(Set value: Not Available, Home,
Position 1 to Position 99)
: Return Mode
(Set value: Not Available, Return, Event)
: Return Interval
(Set value: 1 to 65535 seconds)
: Black & White
(Set value: Not Available, Color, Black
& White, Auto)
: Message Packet
(Set value: Available, Not Available)
: FTP
(Set value: Available, Not Available)
: Shutdown
(Set value: Available, Not Available)
Off : Do not use Relay Alarm.
Ⅵ
Other Triggers
For setting alarm activation via methods other
than alarm input.
3
Preset Position
On : Alarm Output
(Set value: Not Available, OUT1, OUT2)
: Black & White
(Set value: Not Available, Color, Black
& White, Auto)
: Massage Packet
(Set value: Available, Not Available)
Off : Do not use "Preset Position" Alarm.
4
Black & White
On : Alarm Out
(Set value: Not Available, OUT1, OUT2)
: Go to a Preset Position
(Set value: Not Available, Home,
Position 1 to Position 99)
: Return Mode
(Set value: Not Available, Return, Event)
: Return Interval
(Set value: 1 to 65535 seconds)
: Massage Packet
(Set value: Available, Not Available)
Off : Do not use Black & White Alarm.
Ⅵ
Alarm Out
For performing setting related to output during
an alarm activation.
5
OUT1/OUT2
On : Output Value
(Set value: ON, OFF)
: Pattern
(Set value: Level, Momentum)
: Momentum Interval
(Set value: 1 to 5000 milliseconds)
Off : Do not output alarm.
5-4 Setting Using the Web Browser (7. Alarm Setting) (Continued)
Notes
● Set output settings according to settings of
the device for which alarm output is sent to.
● When alarm setting is complete, always
check to ensure that the alarm is functioning
correctly.
