Jensen MP8610BT User Manual

Page 16

MP8610BT

Operation (continued)

Audio Menu (continued)

Middle Range (MID)

When in the Mid range menu, use the left (

) or right (

) joystick button to select the Middle

Range parameter you would like to adjust.

•

LEVEL: Use the up (+) or down (-) joystick button to adjust the Middle Range level from
“-6” to “+6”.

•

C.FREQ: Use the up (+) or down (-) joystick button to adjust the Middle Range center fre-
quency (C.FREQ) to “500Hz”, “1KHz”, “1.5KHz”, or “2.5KHz”.

•

MID-Q: Use the up (+) or down (-) joystick button to adjust the Middle Quality Factor to
“2N”, “1N”, “1W” or “2W”.

NOTE: For quick access to “MID” once inside the Audio menu, press RPT/3.

Treble

When in the Treble menu, use the left (

) or right (

) joystick button to select the desired

Treble parameter you would like to adjust.

•

LEVEL: Use the up (+) or down (-) joystick button to adjust the Treble level from “-6” to
“+6”.

•

C.FREQ: Use the up (+) or down (-) joystick button to adjust the Treble center frequency
(C.FREQ) to “10KHz”, “12.5KHz”, “15KHz”, or “17.5KHz”.

NOTE: For quick access to “Treble” once inside the Audio menu, press RDM/4.

Loud

When in the Loud menu, use the up (+) or down (-) joystick button to turn the loudness “ON” or
“OFF”. Once Loud is turned “ON”, use the left (

) or right (

) joystick button to select the

desired Loudness parameter you would like to adjust:

•

LEVEL: Use the up (+) or down (-) joystick button to adjust the loudness level to “Low”
(+6dB), “Mid” (+10dB) or “High” (+15dB).

•

P. FREQ: Use the up (+) or down (-) joystick button to adjust the loudness Peak Frequency
(P. FREQ) to “400Hz”, “800Hz” or “2.4KHz”.

•

BOOST: Use the up (+) or down (-) joystick button to adjust the Boost mode to “Flat” or
“On” mode.

NOTE: For quick access to “Loud” once inside the Audio menu, press F-/5.

Subwoofer

The Subwoofer control is only applicable if a subwoofer is connected to the unit.

When in the Sub-W menu, use the up (+) or down (-) joystick button to turn the sub-woofer
“ON” or “OFF”. Once the Subwoofer option is turned on, use the left (

) or right (

) joystick

button to select the desired Subwoofer parameter you would like to adjust:

•

LEVEL: Use the up (+) or down (-) joystick button to adjust the Sub-woofer level from “0” to
”12”.

•

LPF: Use the up (+) or down (-) joystick button to adjust the Low Pass Filter (LPF) to “Flat”,
“80Hz”, “120Hz” or “160Hz”.

NOTE: For quick access to ‘Sub-W’, once inside the Audio menu, press F+/6.

Audio Control / Regulador Audio / Contrôleur Audio
