18
INITIAL SETTINGS
Auto Channel Set/Auto Clock Set/Auto Guide
Programme Number Set
1
Press A on the unit or AUDIO A on the remote control to
turn on the unit. The AUTO SET/T-V LINK display appears on
the TV screen.
2
Press selection keys to select AAUTO SETB, then press
ENTER.
● Auto Channel Set is
performed.
● When Auto Channel Set
is completed,
ASCAN
COMPLETED B appears
on the TV screen.
ATTENTION:
AAUTOB blinks on the front
display panel; do NOT
press any button on the unit
or remote control until the
front display panel shows
clock time,
APR1B or
AcB as illustrated on
page 20.
● When you have
connected the unit to a TV
offering T-V Link via a fully-wired 21-pin SCART cable (A pg. 13)
and the TV is turned on, the unit automatically performs the
Preset Download (A pg. 19) even if you select
AAUTO SETB for
Auto Set Up function.
NOTES:
● In areas where no TV station transmits a PDC (Programme
Delivery Control) (A pg. 49) signal, the unit can perform neither
Auto Clock Set nor Auto Guide Programme Number Set.
● If there is a power cut, or if you press A or SET UP while AAuto
Set Up B is in progress, AAuto Set UpB will be interrupted. Be sure
to turn off the unit power once and try again from step 1.
● Auto Clock Set may not function properly depending on the
reception condition.
Auto Set Up
After the A button on the unit (or AUDIO A on the remote
control) is pressed for the first time to turn on the unit, the Auto
Set Up function sets the tuner channels, clock and Guide
Programme numbers automatically.
Before starting, make sure of the following:
● The TV aerial cable should be connected to the unit.
● The unit’s mains power cord should be connected to a mains
outlet.
● Turn on the TV and select an input mode such as EXT1.
● Set the remote control selector switch to AUDIO.
● Press DVD on the remote control.
1 2 3
4 5 6
7 8 9
0
VOL
SAT
TV
AUDIO
( FGDE)
ENTER
AUDIO A
1
Selection Keys
INITIAL SET UP
AUTO SET
INITIAL SET UP / CHANNEL SET
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
T-V LINK
RETURN
OK
SELECT
SET UP
ATTENTION:
Once you have performed
AAuto Set UpB, even if the unit’s
memory backup has expired, all the stored stations and their
Guide Programme numbers remain in the unit’s memory and the
unit will not perform
AAuto Set UpB again. Perform clock set
manually after turning on the unit. (A pg. 81)
If you have moved to a different area, perform each setting as
required.
● TV Tuner setting (A pg. 78)
● Clock setting (A pg. 81)
If a new station starts broadcasting in your area, perform TV
tuner setting. (A pg. 78)
After AAuto Set UpB is completed, perform AMonitor SetB
(A pg. 21).
INITIAL SET UP
AUTO SET
INITIAL SET UP / CHANNEL SET
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
T-V LINK
AUTO SET
PLEASE WAIT...
CANCEL
RETURN
OK
SELECT
SET UP
