32
5
When the adjustment is correctly done, stop
playback of the selected components or
speaking into the microphone.
6
Press 3 PLAY.
Recording starts. The REC indicator flashes on the display.
7
Start playback of the selected components or
speaking into the microphone.
To stop recording for a moment, press PAUSE 8 for CD
Recorder on the unit or 8 on the remote control. To resume play,
press PLAY 3 for CD Recorder on the unit or 3 on the remote
control. (A track mark is recorded when you resume recording.)
To stop during recording, press STOP 7 for CD Recorder on
the unit, or 7 on the remote control. “STOP DUBBING” flashes
on the display for a while.
To eject the disc, press EJECT 0.
“FINALIZE ?” appears on the display.
—To finalize, press FINALIZE or SET. After finalizing, the disc
is ejected.
—Not to finalize, press EJECT 0 again or wait for 5 seconds
so that the disc comes out without being finalized.
MIX BALANCE
LINE
MIC CD
LINE
MIX BALANCE
LINE
MIC CD
LINE
CD+LINE
Reduce recording
level of CD. Reduce recording
level of line input.
CD+MIC
Reduce recording
level of CD. Reduce recording
level of microphone.
LINE+MIC
Reduce recording
level of line input. Reduce recording
level of microphone.
Recording from the Two Sources Mixed—Sound Mixing Recording
You can record sounds mixing 2 sources. When using this method, analog recording is always performed.
• Recording can be also stopped automatically when the playback sound stops coming in (see page 33).
• While mixing, no sounds come out of the DIGITAL OUT terminals.
IMPORTANT
When using operating buttons (
3, 7, 8) on the remote control, check which indicator lights up on the display—CD PLAYER (3-CD
Changer) or CD RECORDER. If the incorrect indicator is lit, press CONTROL CD or CONTROL CDR to select the correct target source.
1
Load discs onto the 3-CD Changer disc trays and
a recordable CD-R or CD-RW onto the CD
Recorder disc tray.
2
Press REC SOURCE SELECTOR on the unit or
REC SOURCE on the remote control to select a
source to record from.
Selected recording source lamps on the unit light up.
CD+LINE MIX :Records mixed sound of 3-CD Changer
and an external component through the
LINE IN jacks. The CD and LINE lamps
light up.
CD+MIC MIX :Records mixed sound of 3-CD Changer
and a microphone through the MIC jack.
The CD and MIC lamps light up.
LINE+MIC MIX :Records mixed sound of an external
component through the LINE IN jacks
and a microphone connected to the MIC
jack. The LINE and MIC lamps light up.
3
Press ¶ REC/REC MUTING.
The unit enters recording pause mode. The remaining
time of CD-R or CD-RW is shown on the display. The
8
and REC indicators light up on the display.
• If OPC (see page 42) is being performed, “UPDATE
OPC” flashes on the display.
4
Start playback of the selected components or
speaking into the microphone to adjust the
recording level and mixing balance.
1) Adjust the recording level.
See details on page 23.
2) Turn MIX BALANCE control on the unit to
adjust the mixing balance.
COMPACT
DIGITAL AUDIO Recordable ReWritable
MIN MAX
COMPACT
DIGITAL AUDIO
XL – R5020 CD/CDR MULTIPLE COMPACT DISC RECORDER
On the unit: Remote control:
CA NC
EL
R EC
SO UR CE
DI SP LA Y ME NU
1
PLAY
CD REC CD EDIT SYNCHRO FADE
REC PITCH 0
PITCH
FINALIZE
REC MUTING
MODE
SET
GROUP
REPEAT CD CDR
4
7
10
2
5
8
3
6
9
10 GROUP
CONTROL
GROUP
¶ REC/
REC MUTING
EJECT 0
Recording
source lamps
PAUSE 8
8
REC SOURCE
SELECTOR
REC SOURCE
3
PLAY 3
¶ REC/REC MUTING
CD Recorder
disc tray 3-CD Changer
disc trays REC
LEVEL
+/−
MIX BALANCE
Source
