Specifications
7 Center unit (XV-THA75R)
Output Power
FRONT/CENTER/SURROUND/SURROUND BACK:
20 W
× 6, 4 Ω, 1 kHz, 0.7% THD
30 W
× 6, 4 Ω, 1 kHz, 10% THD
SUBWOOFER:
100 W, 4
Ω, 100 Hz, 0.7% THD
140 W, 4
Ω, 100 Hz, 10% THD
Audio section
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
STB/VCR/TV SOUND:
340 mV/47 k
Ω
Digital input*:
DIGITAL IN (STB):
–21 dBm to –15 dBm
(660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and
DTS Digital Surround (with sampling frequency —
32 kHz, 44.1 kHz, 48 kHz)
Video section
Color System:
PAL
Horizontal Resolution:
500 lines
Signal-to-Noise Ratio:
70 dB
(Composite signal when
“RGB” is selected)
VIDEO output sensitivity/Impedance (at 1 kHz)
Composite:
1.0 V(p-p)/75
Ω
S-video-Y:
1.0 V(p-p)/75
Ω
S-video-C:
0.286 V(p-p)/75
Ω
VIDEO input sensitivity/Impedance (at 1 kHz)
Composite:
VCR IN, STB IN:
1.0 V(p-p)/75
Ω
S-video-Y:
VCR IN, STB IN:
1.0 V(p-p)/75
Ω
S-video-C:
VCR IN, STB IN:
0.286 V(p-p)/75
Ω
RGB:
0.7 V(p-p)/75
Ω
Tuner section
Tuning Range
FM:
87.50 MHz – 108.00 MHz
AM (MW):
522 kHz – 1 629 kHz
General
Power Requirements:
AC 230 V
Ó, 50 Hz
Power Consumption:
165 W (at operation)
2.5 W (in standby mode)
Dimensions:
435 mm
× 70 mm × 353 mm
(W
× H × D)
Mass (approx.):
5.0 kg
7 Subwoofer (SP-WA75)
Speaker:
20 cm
Bass-reflex, Magnetically
Shielded type
Power Handing Capacity:
140 W
Impedance:
4
Ω
Frequency Range:
25 Hz to 200 Hz
Dimensions:
200 mm
× 410 mm × 428 mm
(W
× H × D)
Mass (approx.):
9.1 kg
7 Satellite Speakers (SP-XSA75)
Speakers:
7 cm
× 4 cm
Bass-reflex, Magnetically
Shielded type
Power Handling Capacity:
30 W
Impedance:
4
Ω
Frequency Range:
110 Hz to 20 kHz
Dimensions:
62 mm
× 102 mm × 109 mm
(W
× H × D)
Mass (approx.):
440 g
7 Center Speaker (SP-XCA75)
Speaker:
7 cm
× 4 cm
Bass-reflex, Magnetically
Shielded type
Power Handling Capacity:
30 W
Impedance:
4
Ω
Frequency Range:
100 Hz to 20 kHz
Dimensions:
152 mm
× 62 mm × 109 mm
(W
× H × D)
Mass (approx.):
475 g
7 Accessories
Remote control (1)
Batteries (2)
FM antenna (1)
AM (MW) loop antenna (1)
Composite video cord (1)
Speaker cords
Approx. 5 m (3) with a mini plug:
For the left front speaker, right front
speaker, and center speaker
Approx. 5 m (1): For subwoofer
Approx.. 10 m (3) with a mini plug:
For the left surround speaker, right
surround speaker, and surround back
speaker
Satellite speaker wall brackets (5)
Screws for the sattelite speaker wall brackets (5)
Designs & specifications are subject to change without notice.
