Connecting the power cord
Make sure that all connections have been made before plugging the power cord.
SURROUND SPEAKERS SURROUND BACK VCR
RGB Y/C
STB
COAXIAL
AM LOOP
(STB)
RIGHT LEFT SPEAKER
VCR IN
AV COMPU LINK- S-VIDEO
AV
DIGITAL IN
ANTENNA
STB IN OUT
AUDIO IN
VIDEO
R L R L
CENTER RIGHT SUBWOOFER LEFT SPEAKER
CAUTION:SPEAKER IMPEDANCE 4 16
FM 75
AM EXT
FRONT SPEAKERS
Plug into
AC outlet.
Power cord
CAUTIONS:
• Disconnect the power cord before cleaning or moving the system.
• Do not touch the power cord with wet hands.
• Do not pull on the power cord to unplug the cord.
When unplugging the cord, always grasp the plug so as not to damage the cord.
NOTES:
• Keep the power cord away from the connecting cords. The power cord may cause noise or screen interference.
• The preset settings such as preset stations, and sound adjustment may be erased within a few days in the following cases:
– When you unplug the power cord.
– When a power failure occurs.
