NOTES:
• Disconnect the supplied FM antenna before attaching a 75 Ω coaxial connector (the kind with a round wire going to an outdoor antenna).
• We recommend that you use a coaxial cable (not supplied) to the FM antenna, since it is well-shielded against interference.
SURROUND SPEAKERS SURROUND BACK VCR
RGB Y/C
STB
COAXIAL
AM LOOP
(STB)
RIGHT LEFT SPEAKER
VCR IN
AV COMPU
LINK- S-VIDEO
AV
DIGITAL IN
ANTENNA
STB IN OUT
AUDIO IN
VIDEO
R L R L
CENTER
RIGHT SUBWOOFER LEFT SPEAKER
CAUTION:SPEAKER IMPEDANCE 4 16
FM 75
AM EXT
FRONT SPEAKERS
7 FM antenna
Extend the supplied FM antenna horizontally.
If reception is poor:
Connect an outdoor FM antenna
with the standard type (coaxial)
connecter.
Outdoor FM antenna
(not supplied)
Outdoor FM antenna cord (not supplied)
Connecting the supplied FM antenna
