Tempstar/HH GPX Series Technical Manual 7610-002-57-32
Issued: 07-24-2006 Revised: N/A
SECTION 6: PARTS SECTION
EXHAUST FAN CONTROL OPTION/SAFETY DOOR INTERLOCK (SDI) OPTION
49
Exhaust Fan Control
Delay Timer
05945-011-65-44
Exhaust Fan Control
2” Din Rail
05700-002-36-09
Exhaust Fan Control
Terminal Board
05940-011-84-41
Safety Door Interlock Box Bottom
05700-001-21-26
Other Safety Door Interlock (SDI) components (not shown):
Pipe Clamp (found on the side of the machine) 05700-000-35-05
Solenoid, Electrical Interlock Option 04810-100-61-33
Relay 05945-111-47-51
Safety Door Interlock Box Cover
05700-001-21-27
