Tempstar/HH GPX Series Technical Manual 7610-002-57-32
Issued: 07-24-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
DIMENSIONS FOR TEMPSTAR HH GPX
5
LEGEND:
A
- DRAIN 1 1/2” NPT
B - WATER INLET 1/2” NPT
C - ELECTRICAL CONNECTION
D
- STANDARD WALL CLEARANCE WITH DISHTABLE 4”
E
- OUTLET TO BOOSTER HEATER 3/4” N.P.T.
F - INLET FROM BOOSTER HEATER 3/4” N.P.T.
ALL DIMENSIONS ARE +/- 1/2” DUE TO ADJUSTABLE FEET.
1”
11”
34”
TABLE
HEIGHT
17”
MACHINE
OPENING
74 3/4”
86 1/4”
W/ DOOR
OPEN
19”
3”
12 1/4”
12 3/4”
16 1/4”
5” 7 1/4”
4 1/4”
32”
25 1/4”
A
C
B
F
F
E
D
D
