Accessories
Everio Dock
CU-VC3U ( ੬ below)
AC Adapter
AP-V14E
Power Cord Battery Pack
BN-VF808U
Audio/Video Cable USB Cable
( ੬ pg. 38, 40 and
PC OPERATION
GUIDE)
Shoulder Strap
( ੬ pg. 7)
CD-ROM
( ੬ PC OPERATION
GUIDE)
NOTE
Make sure to use the provided cables for
connections. Do not use any other cables.
Remote Control Unit
RM-V750U ( ੬ pg. 7)
Lithium Battery
CR2025
Pre-installed in the
remote control unit.
How to Use the Everio Dock
You can connect cables to the connectors of the Everio dock. The connection is completed when
you place the camera on the dock.
NOTE
For the connection using the S connector and DV Connector, an optional S-Video cable and DV cable
are needed. To purchase these cables, consult the JVC Service Center described on the sheet included
in the package for details on its availability. Make sure to connect the end with a core fi lter to the
camera. The core fi lter reduces interference.
• The S-Video cable (optional) enables even higher quality playback on TV. ( ੬ pg. 29) Be sure to use
the YTU94146A S-Video cable.
• When dubbing fi les from the camera using a VCR/DVD recorder ( ੬ pg. 44)
, using the DV cable
enables even higher quality dubbing. Be sure to use the VC-VDV204U DV cable. Operation using the
DV cable is not guaranteed on all of the devices.
Camera
Connection
Terminal
S Connector
AV Connector
DC Connector
DV Connector
USB
Connector
