Troubleshooting—GS2 Display 1800
Continued on next page CF86321,0000335 -19-23MAY11-1/2
Diagnostic Addresses
Diagnostic Addresses
NOTE: Diagnostic addresses are available to access
specific diagnostic information. This information
can assist the John Deere Dealer in diagnosing
problems. Different device controllers can be
selected from drop-down box, as shown.
Select DIAGNOSTIC ADDRESSES button. The
number of devices available will depend upon machine
configuration. The list of addresses can be scrolled up or
down with rotary thumb wheel. Selecting an address will
show data for that address.
PC8663 —UN—05AUG05
MENU button
PC8655 —UN—05AUG05
MESSAGE CENTER button (With Info Icon)
PC8668 —UN—05AUG05
DIAGNOSTIC ADDRESSES softkey
Address Number Address Name
008 Unswitched Power Supply Voltage
009 Switched Power Supply Voltage
010 Unit Internal Temperature
011 Vehicle CAN - Bus Status
012 Vehicle CAN - CAN HIGH Voltage
013 Vehicle CAN - CAN LOW Voltage
015 Implement CAN - Bus Status
016 Implement CAN - CAN HIGH Voltage
017 Implement CAN - CAN LOW Voltage
018 Flash Wear Count
019 Hours of Operation
020 1.5 v Regulated Power Supply Voltage
021 3.3 v Regulated Power Supply Voltage
022 5.0 v Regulated Power Supply Voltage
023 Radar Input Status
024 Implement Switch Status
025 External Analog Input Voltage
026 Compact Flash Drive Status
028 CCD Bus - Bus Status
029 CCD Bus - Positive Voltage
030 CCD Bus - Negative Voltage
031 Bezel Key Status
032 Real Time Clock (RTC)
033 Maximum Sleep Time
038 Synchronize Brightness
039 Daytime Luminance
040 Daytime Luminance Balance Ratio
041 Nighttime Luminance
042 Nighttime Luminance Balance Ratio
