Troubleshooting—GS2 Display 1800
Continued on next page CF86321,0000333 -19-23MAY11-1/2
Guidance Alarms
ACI Communication Error No communication with vehicle steering controller (Steering Controller). Check vehicle for diagnostic codes
and contact your John Deere Dealer.
Turn Predictor Turned On Turn predictor is turned ON. Use the check box to turn it OFF
AutoTrac Deactivated AutoTrac system deactivates when operator is out of seat for more than 5 seconds
AutoTrac The operator is responsible for collision avoidance. Turn AutoTrac OFF before entering roadways.
Data Card Problem! A data card must be inserted in the compact flash drive with the door closed to use the GreenStar2 Pro
application.
No Setup Data! Setup data for the GreenStar2 Pro application could not be found on the data card. The GreenStar2 Pro
application will not be available until a data card with setup data is inserted
AutoTrac Steering Controller
Software Incompatible See your John Deere Dealer for Steering Controller update.
Communication Error Communication problem with controller. Check connections to controller.
Mobile Processor Detected Mobile Processor Detected on CAN Bus. GreenStar Application is disabled. Remove mobile processor
and cycle power to enable GreenStar application.
GPS Communication Problem No communication with GPS receiver. Check connections at GPS receiver.
Tracking Inaccurate The GPS receiver must be set to report at the 5Hz message output rate. Confirm settings on GPS receiver
and change output to 5Hz,
Invalid Boundary An invalid boundary has been recorded. You may continue recording or clear the current boundary and start
recording again.
Activation Error Invalid activation code. Please reenter activation code.
Invalid Filter All the fields that are required to be filled out based on the Totals Type Selected have not been filled out.
Flags of Same Selection Selected the Flags of same name and mode.
Name Already Exists The name you have entered already exists in this list. Please enter a new name.
Alarms
GPS Communication Problem No communication with GPS receiver. Check connection at GPS receiver and perform operation again.
Curve Track Memory Full Internal memory available for Curve Track is full. Data must be cleared to continue Curve Track Operation.
Clear curved track data from system
AutoTrac Disabled AutoTrac SF1 license cannot operate with current StarFire software. Update StarFire software to operate
AutoTrac.
AutoTrac Disabled AutoTrac SF1 license cannot operate while SF2 corrections are turned on. Turn SF2 corrections off to
operate AutoTrac.
License Problem No license available for the selected tracking mode. Previous tracking mode will be selected.
Duplicate Name Name already exists. Select another name.
Curve Track Recording Curve Track recording in progress. Cannot perform operation until recording is turned off.
Circle Definition Problem There was an internal error during Circle definition. Redefine the circle.
Circle Definition Problem Communication with GPS receiver was lost during circle definition. Redefine the circle once communication
has been re-established.
Circle Definition Problem Center point is too far. Select another center point.
A-B Line Definition Problem There was an internal error during A-B line definition. Redefine the A-B line.
A-B Line Definition Problem A timeout occurred during A-B line definition. Redefine the A-B line.
A-B Line Definition Problem A and B points of the A-B line are too close. Perform operation again.
Loss of GPS While Recording
Boundary GPS has been lost while recording the boundary. Point logging will resume when the GPS signal returns. This
may result in an inaccurate boundary.
Data Card Full Unload and cleanup data card or insert new data card.
Data Card 90% Full Unload and cleanup data card or insert new data card.
No Memory No Memory available for Curve Track. Unload and cleanup data card or insert new data card.
Low Memory Low Memory available for Curve Track. Unload and cleanup data card or insert new data card.
No Memory No Memory available for Straight Track. Unload and cleanup data card or insert new data card.
No Memory No Memory available for Circle Track. Unload and cleanup data card or insert new data card.
Circle Definition Problem The distance from the vehicle to the center point is greater than 1 mile. Select another center point or drive
another circle.
Zero All Totals You have decided to zero all totals for the selected filter.
Incorrect RS232 Controller Model
Selected The RS232 controller model selected is incorrect. Please verify and reenter manufacturer and model number.
Prescription Error Controller is not setup to accept prescriptions.
35-3 090811
