Page 47

Troubleshooting—GS2 Display 1800
CF86321,0000333 -19-23MAY11-2/2
CF86321,0000334 -19-23MAY11-1/1
Prescription Error
Controller is setup to accept prescriptions. No controller prescription has been selected.
Prescription Error
Prescription rate is out of controller range.
Controller Unit of Measure Error
Controller will only operate when using metric units.
Controller Unit of Measure Error
Controller will only operate when using English (US) units.
Controller Unit of Measure Error
Controller will only operate when using metric or English (US) units.
Controller Operation Error
Invalid operation selected for controller.
Prescription Warning
Out of field prescription rate is now being applied.
Prescription Warning
Loss of GPS signal has occurred. Loss of GPS prescription rate is now being applied.
Prescription Warning
Controller does not support selected prescription.
INFO
AutoTrac Deactivation Message
AutoTrac deactivation message–Each time AutoTrac
is deactivated text is displayed indicating the reason
why AutoTrac deactivated. Messages are also displayed
as to why AutoTrac did not activate. The deactivation
messages display for 3 seconds and then disappear.
AutoTrac Deactivation Message
Deactivation Message
Description
Steering wheel moved
Operator turned steering wheel
Speed too slow
Vehicle speed is below minimum required speed
Speed too fast
Vehicle speed is above maximum allowed speed
Invalid gear
Vehicle operating in an invalid gear
Track number changed
Track number changed
Invalid GPS signal
SF1, SF2, or RTK signal was lost
Steering Controller fault
See John Deere dealer
Invalid display messages
Check display settings
Invalid display settings
Check guidance settings and Track 0 setup
No AutoTrac Activation
No AutoTrac Activation on GS2
Heading error too large
Vehicle is at an angle greater than 45 degrees from track
Offtrack error too large
Vehicle not within 40% of track spacing
Out of seat
Out of seat too long
Oil temp too cold
Hydraulic oil not above minimum required temperature
No TCM corrections
Make sure TCM is turned on
Invalid Steering Controller activation
Need Steering Controller activation code.
See John Deere dealer.
FICA in diagnostic mode
Fuse is in diagnostic slot in vehicle fuse box. remove fuse.
Header off
Header was turned off
Road mode
In transport gear
Invalid Steering Controller voltage
See John Deere dealer
Reverse timeout
In reverse gear for more than 45 seconds
Vehicle too slow
AutoTrac below minimum speed
Curve too sharp
Maximum curvature has been exceeded
Vehicle not moving in a forward direction
Vehicle must be in forward gear to activate
Vehicle shutting down
Vehicle is shutting down
Gear data error
See John Deere dealer
Resume switch error
See John Deere dealer
Keyswitch error
See John Deere dealer
SPFH AutoTrac switch is not on
Make sure SPFH AutoTrac switch is turned on
SPFH Quick Stop switch is on
Make sure SPFH Quick Stop switch is turned off
