9
Chapter 3 Connection
This chapter describes how to connect peripherals, switches and indicators to the
SAGP-845EV board.
Table of Connectors
Label Function
FDD1 Floppy Disk Drive Connector
IDE1 Primary IDE Connector
IDE2 Secondary IDE Connector
LPT1 Parallel Port Connector
COM1, COM2 Serial Port Connectors
KBM1 PS/2 MOUSE & KEYBOARD Connector
USB1~USB3 USB Connectors
IR1 IrDA connector
FAN1~FAN3 Fan Connectors
LAN1 LAN RJ45 Connectors
CN3 LAN Status LED Connectors
VGA1 VGA 15-pin Female Connector
CN4 AUDIO Connector
CFA1 Compact Flash Socket
CN2 External Switches and Indicators
PW1 ATX BUTTON (Power ON) Switch
PW2 ATX-12V CPU Power Source
S1 CPU voltage setting
