12

3.3 Parallel

Port

This port is usually connected to a printer. SAGP-845EV includes an on-board

parallel port accessed through a 26-pin flat-cable. Three modes― SPP, EPP and

ECP― are supported.


• LPT1: Parallel Port Connector

PIN Description PIN Description

1 STROBE#

2 DATA

0

3 DATA

1

4 DATA

2

5 DATA

3

6 DATA

4

7 DATA

5

8 DATA

6

9 DATA

7

10 ACKNOWLEDGE

11 BUSY

12 PAPER

EMPTY

13

PRINTER SELECT

14

AUTO FORM FEED #

15 ERROR#

16 INITIALIZE

17

PRINTER SELECT LN#

18

GROUND

19 GROUND

20 GROUND

21 GROUND

22 GROUND

23 GROUND

24 GROUND

25 GROUND

26 NC

1

14

13

26
