IBM PSB Form Factor Board SAGP-845EV User Manual

Page 37

IRQ3/4/5/7/9/10/11/12/14/15 assigned to

This item allows the user to determine the IRQ assigned to the ISA bus and is not

available to any PCI slot. Legacy ISA for devices compliant with the original PC

AT bus specification, PCI/ISA PnP for devices compliant with the Plug and Play

standard whether designed for PCI or ISA bus architecture.

The choice: PCI Device, Reserved.

PCI/VGA Palette Snoop

Leave this field disabled.

The choice: Enabled, Disabled.

4.11 PC Health Status

PC Health Status

VCORE 1.44V

+1.5V 1.47V

+3.3V 3.26V

+5.0V 5.05V

+12V 11.58V

-12V (-)11.45V

Current CPU Temp 25°C

Fan 1 (CPU) Spend 5443

Fan 2 (SYSTEM) Spend 0

Fan 3 (SYSTEM) Spend 0

Item Help

-------------------------

Menu Level ¾

↑↓←→ Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit

F1: General Help

F5: Previous Values F6: Fail-safe defaults F7: Optimized Defaults

Note: Normal CPU Fan RPM is over than 5000 RPM. If the CPU Fan RPM is less

than that figure, it means something is wrong and the CPU will be in an overheat

condition. Make sure that the connection at Fan1/Fan2 is correct.
