22
4.5 Standard CMOS Setup
The items in Standard CMOS Setup Menu are divided into 10 categories. Each
category includes none, one or more than one setup items. Use the arrow keys
to highlight the item and then use the or keys to select the
wanted value for each item.
CMOS Setup Utility – Copyright© 1984-2000 Award Software
Standard CMOS Features
Date: Wed, Nov 20 2002
Time: 16:19:20
IDE Primary Master HD Model Name
IDE Primary Slave None
Secondary Master None
IDE Secondary Slave None
Drive A 1.44M, 3.5 in.
Drive B None
Video EGA/VGA
Halt On All,But Keyboard
Based Memory 640K
Extended Memory 65535K
Total Memory 1024K
Item Help
Menu Level ¾
Change the day,
month,
year and century
↑↓←→Move Enter: Select +/-/PU/PD: Value F10:Save ESC: Exit
F1:General Help
F5:Previous Values F6:Fail-safe defaults F7:Optimized Defaults
Figure 1: The Main Menu
