IDE Adapters

The IDE adapters control the hard disk drive. Use a separate sub menu to

configure each hard disk drive.

Figure 2 shows the IDE primary master sub menu.

IDE Primary Master

IDE HDD Auto-Detection Press Enter

IDE Primary Master Auto

Access Mode Auto

Capacity 15362 MB

Cylinder 29765

Head 16

Precomp 0

Landing Zone 29764

Sector 63

Item Help

Menu Level ¾¾

To auto-detect the HDD’s

size, head... on this

channel

↑↓←→Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit

F1: General Help

F5: Previous Values F6: Fail-safe defaults F7: Optimized Defaults

Figure 2 IDE Primary Master Sub Menu

Use the legend keys to navigate this menu. Use Table 2 to configure the hard

disk.

Item

Options

Description

IDE HDD Auto-

detection

Press Enter

Press Enter to auto-detect the HDD on

this channel. If detection is

successful, it fills the remaining fields

on this menu.

IDE Primary Master

None

Auto

Manual

Selecting ‘manual’ lets you set the

remaining fields on this screen.

Selects the type of fixed disk. "User

Type" will let you select the number of

cylinders, heads, etc. Note:

PRECOMP=65535 means NONE !

Capacity Auto

Display

your disk drive

size

Disk drive capacity (Approximated).

Note that this size is usually slightly

greater than the size of a formatted

disk given by a disk checking program.

Access Mode

CHS

LBA

Large

Auto

Choose the access mode for this hard

disk

Table 2 Hard Disk Selections
