5
Bi-directional parallel port Configurable to LPT1, LPT2, LPT3 or disabled
Supports EPP/ECP/SPP
Hardware monitor Monitors power supply voltage and fan speed status
IrDA port
Supports Serial Infrared (SIR) and Amplitude Shift
Keyed IR (ASKIR) interface
USB port Supports 4 USB2.0 ports for future expansion
Watchdog timer
− Programmable
− Reset generated when CPU does not periodically
trigger the timer
− The BIOS routine INT15 can be used to control the
watchdog and generate a system reset
VGA controller
− Built-in AGP2.0 4X 3D graphics engine
− Share system DDR SDRAM 8M
− Screen Resolution: up to 2048x1536x16 bit
Ethernet
− ICH4 Fast Ethernet controller, IEEE 802.3u Auto-
Negotiation support for 10BASET/100BASE-TX
standard
− One RJ45 connector is located on the mounting
bracket
Keyboard and PS/2 mouse
connector
− A 6-pin mini DIN connector is located on the
mounting bracket for easy connection to a
keyboard or PS/2 mouse.
− For alternative applications, a keyboard and a PS/2
mouse pin header connectors are also available on
board.
Audio
− CMI8738LX supports 6CH DAC for AC3 5.1 channel
purpose
− HRTF-based positional audio, support Directsound
3D and A3D interface
Compact flash
It can be used with a passive adapter (True IDE
Mode) in a Type I/II Socket.
Power consumption
− (PENTIUM 4: 2GHz, 1GB PC2100 DDR SDRAM)
+5V @ 4.46A, +12V @ 6.55A.
− (PENTIUM 4-M: 2.5GHz, 512MB PC2100 DDR
SDRAM) +5V @ 4A, +12V @ 3A.
Recommended: 350-watt or higher output power
supply
Operating temperature
0° ~ 60° C
(*CPU needs Cooler & silicone heat sink compound*)
WARNING!
1. Never run the processor without a heat sink (Cooler) properly and firmly
attached.
2. Please use ATX-12V power connector (PW2) to provide power to the CPU.
