9
Chapter 1
Hardware
Installation For ATX586
1.1 One Jumper to Set CPU , Simple Jumper
No more CPU jumper setting when you use Single Processor
Intel 133Mhz,
CYRIX 166
+,
AMD K5-133 CPU.
You just install CPU directly and Power On. (At the moment , JP6: 1-
2 and JP7: 2-3 SHORT; JP8/JP9: 1-2 SHORT )
A: Using Intel CPU (Ensuring JP8/JP9: 1-2 SHORT )
CPU Speed JP6 JP7
Intel 100Mhz 1-2 SHORT 1-2 SHORT
Intel 166Mhz 2-3 SHORT 2-3 SHORT
Intel 200Mhz 2-3 SHORT 1-2 SHORT
Intel 233Mhz 1-2 SHORT 1-2 SHORT
B: Using AMD K5/K6 (Ensuring J P8/9: 1-2 SHORT )
CPU Speed JP6 JP7
AMD K5-100 1-2 SHORT 1-2 SHORT
AMD K5/K6-PR-166 2-3 SHORT 2-3 SHORT
AMD K6-PR200
2-3 SHORT 1-2 SHORT
AMD K6-PR233 1-2 SHORT 1-2 SHORT
C: Using CYRIX 6x86 CPU ( Ensuring JP6: 1-2 and JP7: 2-3 SHORT )
CPU Speed JP8 JP9
CX 133
+
, 55Mhz 2-3 SHORT 2-3 SHORT
CX 150
+
, 60Mhz 2-3 SHORT 1-2 SHORT
CX 200
+
, 75Mhz 1-2 SHORT 2-3 SHORT
When you want to install two CPU, they are perfect are the same
voltage 2.8v (P55C) or 3.3v(P54C). Different voltage can’t be
used together. Installing the 1
st
CPU at U4 socket!
