22
OS Select for DRAM
>64MB : NON-
OS2 F7 : Load Setup Defaults
2.4 Chipset Features Setup
ROM PCI/ISA BIOS (2A59GT4A)
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
Auto Configuration : Enabled DRAM Fast Leadoff : Disabled
DRAM Timing : 60ns Delayed Transaction : Disabled
DRAM RAS# Precharge Time : 3
DRAM R/W Leadoff Timing : 6
DRAM RAS To Cas Relay : 3
DRAM Read Burst(EDO?FP) : 3
DRAM Write Burst Timing :x222/x333
Fast MA To RAS# Delay CLK : 1
Fast EDO path Select : Disabled
Refresh RAS# Assertion : 4 CLKS
ISA Bus Clock : PCICLK/4
System BIOS Cacheable : Disabled
Video BIOS Cacheable : Disabled
8 Bit I/O Recovery Time : 1
↑↓←→
: Select Item
16 Bit I/O Recovery Time : 1 F1 : Help PU/PD/+/- : Modify
Memory Hole At 15M-16M : Disabled F5 : Old Values (Shift)F2 : Color
Peer Concurrency : Enabled F6: Load BIOS Defaults
Passive Release : Enable F7 : Load Setup Defaults
2.5 Power Management Setup
ROM PCI/ISA BIOS (2A59GT4A)
POWER MANAGEMENT SETUP
AWARD SOFTWARE, INC.
Power Management : User Define **power Down & Resume Events **
PM Control by APM : Yes IRQ3 (COM2) : ON
Video Off Method : V/H SYNC+Blank IRQ4 (COM1) : ON
Modem Use IRQ : 3 IRQ5 (LPT2) : ON
Doze Mode : 1 Min IRQ6 (Floppy Disk) : OFF
Standby Mode : 1 Min IRQ7 (LPT1) : ON
Suspend Mode : 1 Min IRQ8 (RTC ALARM) : OFF
HDD Power Down : I Min IRQ9 (IRQ2 Redir) : ON
IRQ10 (Reserved) : ON
** Wake Up Events In Doze & Standby ** IRQ11 (Reserved) : ON
IRQ3 (Wake-Up Event) : ON IRQ12 (PS/2 Mouse) : ON
IRQ4 (Wake-Up Event) : ON IRQ13 (Coprocessor) : ON
IRQ8 (Wake-Up Event) : ON IRQ14 (Hard Disk) : ON
IRQ12 (Wake-Up Event) : ON IRQ15 (Reserved) : ON
↑↓←→
: Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values
F6: Load BIOS Defaults
F7 : Load Setup Defaults
(Shift)F2 : Color
