63
I/O Address and IRQ
On Board I/O
Address IRQ DRQ
GAME 200-20F X X
COM1 3F8-3FF 4 X
COM2 2F8-2FF 3 X
COM3 3E8-3EF 3 X
COM4 2E8-2EF 3 X
IDE1 1F0-1F7 14 X
IDE2 170-177 15 X
LPT1 378-37F 7 3 (ECP)
LPT2 278-27F 7 3 (ECP)
LPT3 3BC-3BF 7 3 (ECP)
FDD1 3F0-3F7 6 2
PS/2 MOUSE X 12 X
4.7 Jumpers and Connectors List
ITEMS DESCRIPTION
JP1 SCSI Port Power Down Mode
JP2 RAID Function Jumper
JP3 Wide SCSI Function Jumper
JP4 Flash BIOS, 12v or 5v
JP5 Set CPU External Bus Frequency ,CPU Type for clock
JP6 Choose AT or ATX Power Supply
JP7 CPU Voltage, 2.8v or 3.3v
JP8 Set CPU External Bus Frequency (BF0, BF1)
JP9 Front Panel Connector
JP10 2-3 Normal CMOS, 3-4 CMOS Clear
J1 ATX Power Supply Connector
J2 AT Power Supply Connector
