23
2.6 PNP/PCI Configuration
ROM PCI/ISA BIOS (2A56GT5A)
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
Resources Controlled By : Manual PCI IRQ Actived By : Level
Reset Configuration Data : Enabled PCI IDE IRQ Map To : PCI-AUTO
primary IDE INT# : A
IRQ-3 assigned to : Legacy ISA Secondary IDE INT# : B
IRQ-4 assigned to : Legacy ISA Used Mem Base Addr : N/A
IRQ-5 assigned to : Legacy ISA
IRQ-7 assigned to : Legacy ISA
IRQ-9 assigned to : Legacy ISA
IRQ-10 assigned to : Legacy ISA
IRQ-11 assigned to : Legacy ISA
IRQ-12 assigned to : Legacy ISA
IRQ-14 assigned to : Legacy ISA
IRQ-15 assigned to : Legacy ISA
DMA-0 assigned to : Legacy ISA
DMA-1 assigned to : Legacy ISA
↑↓←→
: Select Item
DMA-5 assigned to : Legacy ISA F1 : Help PU/PD/+/- : Modify
DMA-6 assigned to : Legacy ISA F5 : Old Values
DMA-7 assigned to : Legacy ISA F6: Load BIOS Defaults
: F7 : Load Setup Defaults (Shift)F2 : Color
2.7 Integrated Peripherals
ROM PCI/ISA BIOS (2A59GT5A)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
IDE HDD block Mode : Enabled USB Controller : Enabled
IDE Promary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO : Auto
IDE Secondary Slave PIO : Auto
On-chip Primary PCI IDE : Enabled
On-Chip Secondary PCI IDE : Enabled
Onboard FDD Controller : Enabled
Onboard Serial Port 1 : 3F8/IRQ4
Onboard Serial Port 2 : 2F8/IRQ3
UART 2 Mode : Standard
Onboard Parallel Port :378H/IRQ7
Onboard Parallel Mode : SPP
↑↓←→
: Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values
: F6: Load BIOS Defaults
F7 : Load Setup Defaults
(Shift)F2 : Color
2.8 AWARD BIOS Post Code
