Intel 430TX User Manual
Page 16
16
JP17:
IR, fast infrared port. PIN-1: IRRX, PIN-2:
GND; PIN-3: IRTX; PIN-4: VCC
COM1-2/CN1-CN5:
Support 16550 high speed
serial ports/ UART.
PS/2 Mouse CN2:
PS/2 mouse port. 5-pin Mouse:
LPT/CN4:
Printer port with ECP/ PP. bi-direction.
It can be used with external IDE/ SCSI device.
AT POWER CONNECTOR/CN6:
For normal AT
style power supply
ATX POWER CONNECTOR/CN7:
For ATX
factor style power supply
USB1/:
4-PIN connectors. PIN-1: VCC(5V),
PIN-2: USB-, PIN-3: USB+, PIN-4: GND
