4.1 One Jumper to Set CPU , Simple Jumper
No more CPU jumper setting when you use
Intel 133Mhz,
CYRIX 166
+,
AMD K5-133 CPU.
You just install CPU directly and Power On. (At the moment, JP8:2-3,
4-5 SHORT; JP5: OPEN )
A: Using Intel CPU (Ensuring JP5: OPEN )
CPU Speed JP8
Intel 100Mhz 1-2, 4-5 SHORT
Intel 166Mhz 2-3, 5-6 SHORT
Intel 200Mhz 1-2, 5-6 SHORT
Intel 233Mhz 1-2, 4-5 SHORT
B: Using AMD K5/K6 (Ensuring JP5: OPEN )
CPU Speed JP8
AMD K5-100 1-2, 4-5 SHORT
AMD K5/K6-PR166 2-3, 5-6 SHORT
AMD K6-PR200
1-2, 5-6 SHORT
AMD K6-PR233 1-2, 4-5 SHORT
C: Using CYRIX 6x86 CPU ( Ensuring JP8: 2-3, 4-5 SHORT)
CPU Speed JP5
CX 133
+
, 55Mhz 1-3, 2-4 SHORT
CX 150
+
, 60Mhz 1-3 SHORT, 2-4 OPEN
CX 200
+
, 75Mhz 2-4 SHORT, 1-3 OPEN
