Intel® Gigabit Ethernet Switch AXXSW1GB User Guide 115
The Basic Mode General Settings Page contains the following fields:
• Ports — Displays the basic mode general settings in the port table.
• LAGs — Displays the basic mode general settings in the LAG table.
• Trust Mode — Defines which packet fields to use for classifying packets entering the
device. The possible Trust Mode field values are:
— CoS — Classifies traffic based on the CoS tag value.
— DSCP — Classifies traffic based on the DSCP values.
• Always Rewrite DSCP — Indicates if the DSCP value is always reassigned based on
values displayed in the DSCP Rewrite table. The possible field values are:
— Checked — Enables reassigning the DSCP value.
— Unchecked — Disables reassigning the DSCP value. This is the default value.
• Interface — Indicates the Interface on which the Trust Mode is disabled.
• Disable Trust Mode — When checked, Trust Mode is disabled.
2. Define the relevant fields.
3. Click .
The QoS General Settings are configure, and the device is
updated.
