6662AX-X-C Page 7 of 8
TORQUE REQUIREMENTS
NOTE: DO NOT OVERTIGHTEN FASTENERS
LUBRICATION / SEALANTS
IMPORTANT
BE CERTAIN TO ORIENT (115) SPACER LEGS
AWAY FROM BLOCKING INTERNAL PORTS
WHEN REASSEMBLING AIR SECTION.
MAJOR VALVE CROSS SECTION DETAIL
109 110 112 114 113 115 111 116
Figure 3
MAJOR VALVE
PILOT VALVE
118
111
112
113
114
115
116
117
119
102
104
123 121
122
120
108 109
110
106
105
See cross section detail Figure 3.
201
128
107
127
126
195
195
101
231
104
102
103
107
106
105
123
121
(105) 40 50 in. lbs (4.5 5.6 Nm),
apply Loctite Nickel Antiseize to threads.
Apply Key-Lube to all “O" rings, ”U" Cups & mating parts.
Apply Loctite 271 to threads.
Apply pipe sealant to threads.
Apply Dri-Loc 204 to threads.
1. PARTS LIST / 6662AX-X-C AIR MOTOR SECTION
