MATERIAL CODE
[A]
= Aluminum
[B]
= Nitrile
[C] = Carbon Steel
[Co] = Copper
[E]
= E.P.R.
[H] = Hytrel
[SP] = Santoprene
[SS] = Stainless Steel
[T]
= PTFE
[V]
= Viton
PW10A-X-X
Page 4 of 8
PARTS LIST / PW10A-X-X FLUID SECTION
L
637401-XX FLUID SECTION SERVICE KITS INCLUDE: BALLS (see Ball Option, refer to -XX in Service Kit chart below), DIAPHRAGMS
(see Diaphragm Option, refer to -XX in Service Kit chart below), and items 19, 70, 144 and 175 (listed below) plus 174 and 94276 Lubri-
plate FML-2 grease (page 6).
SEAT OPTIONS
PW10A-XXX-XXX
BALL OPTIONS
PW10A-XXX-XXX
“21”
L
“22” (1-1/4” dia.)
-XXX
Seat
Qty [Mtl]
-XXX
Ball
Qty [Mtl]
-AXX 96152-A
(4) [SP]
-XAX 93278-A
(4) [SP]
-CXX 96152-C
(4)
[H]
-XCX 93278-C
(4)
[H]
-FXX
96156
(4)
[A]
-XGX 93278-2
(4)
[B]
-GXX 96152-G
(4)
[B]
-XTX
93278-4
(4)
[T]
-XVX
93278-3
(4)
[V]
DIAPHRAGM OPTIONS PW10A-XXX-XXX
L
Service Kit
L
“7”
L
“8”
L
“19”
L
“33”
-XXX
-XX = (Ball)
-XX = (Diaphragm) Diaphragm Qty [Mtl] Diaphragm Qty [Mtl] Gasket
Qty [Mtl] Gasket
Qty [Mtl]
-XXA 637401-XA
96267-A
(2) [SP] - - - - -
- - -
- - - 93280
(4)
[E] 93279
(4)
[E]
-XXC 637401-XC
96267-C
(2)
[H] - - - - -
- - -
- - - Y327-225
(4)
[V] Y327-220
(4)
[V]
-XXG 637401-XG
96267-G
(2)
[B] - - - - -
- - -
- - - Y325-225
(4)
[B] Y325-220
(4)
[B]
-XXT
637401-XT
96146-T
(2)
[T]
96145-A
(2) [SP] 93282
(4)
[T]
93281
(4)
[T]
-XXV
637401-XV
95989-3
(2)
[V]
- - - - -
- - -
- - - Y327-225
(4)
[V] Y327-220
(4)
[V]
NOTE: Gasket items 19 and 33 are not required with seat options -AXX, -CXX and -GXX.
EXTERNAL HARDWARE OPTIONS PW10A-XXX-XXX
PW10A-XXP-
PW10A-XXS-
Item
Description
(size)
Qty Part No.
[Mtl] Part No.
[Mtl]
26 Screw
(M8 x 1.25 - 6g x 30 mm)
(8)
95880-1
[C] 95880
[SS]
27 Screw
(M8 x 1.25 - 6g x 40 mm)
(20) 95896-1
[C] 95896
[SS]
29 Nut
(M8 x 1.25 - 6h)
(20) 95879-1
[C] 95879
[SS]
COMMON PARTS
Item
Description
(size)
Qty Part No.
Mtl
Item
Description
(size)
Qty Part No.
Mtl
1 Rod
(1) 95995
[C]
5 Backup Washer
(2) 95990-3
[C]
6 Diaphragm Washer
(2) 95990-3
[C]
9 Washer
(0.505” i.d.)
(2) 93189-1
[SS]
14 Screw
(M12 x 1.75 - 6g x 25 mm)
(2) 95997
[SS]
15 Fluid Cap
(2) 95935
[A]
43 Ground Lug
(1) 93004
[Co]
60 Inlet Manifold
(1) 96154
[A]
61 Outlet Manifold
(1) 96155
[A]
68 Air Cap
(1) 95994-2
[A]
69 Air Cap
(1) 95994-1
[A]
L n
70 Gasket
(2) 95843
[B]
131 Screw
(M8 x 1.25 - 6g x 95 mm)
(4) 96001
[C]
L n
144 “U” Cup
(3/16” x 1-1/8” o.d.)
(2) Y186-49
[B]
L n
175 “O” Ring
(3/32” x 13/16” o.d.)
(2) Y325-114
[B]
n
180 Washer
(4) 96006
[Co]
195 Nut
(M8 x 1.25 - 6h)
(4) 96005
[SS]
n
Air Section Service Kit Parts, see page 6.
