Invacare Wheelchair Pronto M61 User Manual
Page 65
SECTION 11—BATTERIES
65
Pronto® M51™and M61™with SureStep®
FIGURE 11.3 Connecting/Disconnecting Battery Cables
RED Connectors
POSITIVE (+)
Battery Cable
POSITIVE (+) Battery terminal
NEGATIVE (-) Battery Cable
NEGATIVE (-)
Battery Terminal
Cap
NEGATIVE (-) Battery
terminal
Locknuts
U1 Battery
POSITIVE (+) Battery
Terminal Cap
DETAIL “A”
DETAIL “B”
NOTE: Handles on batteries
removed for clarity.
POSITIVE
(+) Battery
Terminal
NEGATIVE (-) Battery
Terminal
Tie-wraps
U1 Battery
U1 Batteries
BLACK
Connectors
BLACK
Connector to
Controller
Plug into
controller
NOTE: Handles on batteries removed for clarity.
RED Connectors
Mounting Screw
L-Bracket with
Mounting Screw
BLACK
Connectors
NOTE: Battery terminal
caps not shown on front
battery for clarity.
