Invacare Wheelchair Pronto M61 User Manual
Page 52
SECTION 9—FRONT RIGGINGS
Pronto® M51™and M61™with SureStep®
52
4. Using the two socket bolts and locknuts, secure the telescoping front rigging support
to the seat frame as shown in FIGURE 9.6.
5. If necessary, repeat STEPS 2‐4 on remaining telescoping front rigging support.
6. Reinstall the seat. Refer to Removing/Installing the Seat Assembly on page 42.
FIGURE 9.6 Adjusting/Replacing Telescoping Front Rigging Supports - Office Style Seat
FRONT RIGGING
MODEL
STANDARD
POSITION
1 INCH OUT
2 INCHES OUT
18 inches
wide
20 inches
wide
18 inches
wide
20 inches
wide
18 inches
wide
20 inches
wide
PHW93
Holes
4 and 5
Holes
4 and 5
Holes
5 and 6
Holes
5 and 6
Holes
6 and 7
Holes
6 and 7
PH904A and PHAL4A
Holes
3 and 4
Holes
3 and 4
Holes
4 and 5
Holes
4 and 5
Holes
5 and 6
Holes
5 and 6
Spacers
Telescoping Front
Rigging Support
Mounting Holes
Locknuts
Mounting
Bolts
Seat
Inner
Mounting
Holes
2
Not Used
4
3
5
7
6
Hinge
Pins
8
