MATERIAL CODE
[A] = Aluminum
[B] = Nitrile
[C] = Carbon Steel
[CI] = Cast Iron
[Co] = Copper
[D] = Acetal
[E] = E.P.R.
[H] = Hytrel
[K] = Kynar PVDF
[N] = Neoprene
[P] = Polypropylene
[SH] = Hard Stainless Steel
[Sp] = Santoprene
[SS] = Stainless Steel
[T] = PTFE
[U] = Polyurethane
[V] = Viton
637155
ABRASION RESISTANT
CONVERSION KIT
Includes:
93266 (4) [SH] Seat
92757-8 (4) [U] Ball
Service Note: Part no. 98931-T installation tool is available separately for use with items 1 and 2.
V “Smart Parts”, keep these items on hand in addition to the service kits for fast repair and reduction of down time.
66615X-X-C (en) Page 4 of 8
PARTS LIST / 66615X-X-C FLUID SECTION
L 637124-XX Fluid Section Service Kits include: BALLS (see Ball Option, refer to -XX in chart below), DIAPHRAGMS (see Diaphragm Option, refer to -XX
in chart below), 93706-1 Key-Lube grease packet, plus items: 2, 3, 9 and 19.
SEAT OPTIONS BALL OPTIONS
“21” L “22” (1-3/4” dia.)
-XXX Seat Qty [Mtl] -XXX Ball Qty [Mtl] -XXX Ball Qty [Mtl]
-1XX 92760 (4) [A] -X1X 92757-1 (4) [N] -X8X 92757-8 (4) [U]
-2XX 92776 (4) [SS] -X2X 92757-2 (4) [B] -XAX 94804 (4) [SS]
-3XX 92924 (4) [P] -X3X 92757-3 (4) [V] -XCX 92757-C (4) [H]
-4XX 94514 (4) [K] -X4X 92757-4 (4) [T] -XEX 92757-A (4) [Sp]
-5XX 95676 (4) [C] -X5X 92757-5 (4) [E]
-8XX 93266 (4) [SH] -X6X 92757-6 (4) [D]
DIAPHRAGM OPTIONS
L Service Kit L “7” L “8” L “3”
(1/16” x 3/4” o.d.)
L “19”
(1/8” x 2-3/4” o.d.)
-XXX
-XX = (Ball)
-XX = (Diaphragm) Diaphragm
Qty [Mtl] Diaphragm Qty [Mtl] “O” Ring Qty [Mtl] “O” Ring Qty [Mtl]
-XX1 637124-X1 92755-1 (2) [N] - - - - - - - - - - - Y325-16 (4) [B] Y325-230 (4) [B]
-XX2 637124-X2 94615-G (2) [B] - - - - - - - - - - - Y325-16 (4) [B] Y325-230 (4) [B]
-XX3 637124-X3 92755-3 (2) [V] - - - - - - - - - - - Y328-16 (4) [T] Y327-230 (4) [V]
-XX4 637124-X4 94617 (2) [T] 94616 (2) [Sp] Y328-16 (4) [T] Y220-230 (4) [T]
-XX5 637124-X5 92755-5 (2) [E] - - - - - - - - - - - Y328-16 (4) [T] 92761 (4) [E]
-XX9 637124-X9 94615-9 (2) [H] - - - - - - - - - - - Y328-16 (4) [T] Y327-230 (4) [V]
-XXB 637124-XB 94615-A (2) [Sp] - - - - - - - - - - - Y328-16 (4) [T] 92761 (4) [E]
WETTED PARTS OPTIONS
Aluminum Stainless Steel Cast Iron
6661X0-X, 6661XA-X 6661X1-X, 6661XB-X 6661X2-X, 6661XC-X
N.P.T.F. BSP N.P.T.F. BSP N.P.T.F. BSP
Item Description (size) Qty Part No. Part No. [Mtl] Part No. Part No. [Mtl] Part No. Part No. [Mtl]
15 Fluid Cap (2) 92750 92750 [A] 92773 92773 [SS] 92778 92778 [CI]
16 Manifold (2) 92749 92749-1 [A] 92774 92774-1 [SS] 92777 92777-1 [CI]
HARDWARE OPTIONS
Carbon Steel Stainless Steel
6661X0-, 1-, 2- 6661XA-, B-, C-
Item Description (size) Qty Part No. [Mtl] Part No. [Mtl]
5 Plate (air side) (2) 92752 [C] 92775 [SS]
26 Bolt (3/8” - 16 x 1-1/4”) (8) Y6-66-C [C] Y6-66-T [SS]
27 Bolt (5/16” - 18 x 2-1/4”) (4) Y6-510-C [C] Y6-510-T [SS]
29 Nut (5/16” - 18) (20) Y12-5-C [C] Y12-5-S [SS]
32 Leg (2) 92759 [C] 92759-1 [SS]
59 Bolt (5/16” - 18 x 2”) (16) 93608 [C] Y6-59-T [SS]
COMMON PARTS
Item Description (size) Qty Part No. [Mtl] Item Description (size) Qty Part No. [Mtl]
V 1 Rod (1) 98720-1 [C]
L 2 “O” Ring
(3/32” x 1” o.d.) (1) Y330-117 [B]
V 6 Plate
(fluid side) (2) 92775 [SS]
(models 6661X0 only) (2) 92752 [C]
L 9 Washer
(0.630” i.d.) (2) 93065 [SS]
14 Screw (5/8” - 18 x 1-1/2”) (2) Y5-107-T [SS]
43 Ground Lug (see page 7) (1) 93004 [Co]
